主要用途
適用根、莖、草、皮等植物藥材提取及粉碎前的粗切制。
Main uses
Suitable to roughly cut roots
、stems
、grass
、 barks herb into the right size for further processing.
主要特點
切制長度調整方便，傳動可靠、整機強度大、調整簡易、效率高、維修方便。
Main technical characteristics
The cutting length can be adjusted according to different requirements, the machine is efficient and easy to operate and maintain.
主要技術參數 Main technical parameter
型號
Type |
生產能力
Capacity
(kg/h) |
切制長度
herb length
(mm) |
切刀數
Knife number
(mm) |
電機功率
motor
(KW) |
外形尺寸
dimension
(mm) |
總重量
weight
(kg) |
|
JQ200 |
500-1000 |
TypeA20,40,80
TypeB7,14 |
TypeA 2片
TypeB 3片 |
3 |
1500x1000x1800 |
1800 |
